Stellar engine

A mirror the size of a planetary orbit, using a star's own light to push it across the galaxy

Hypothetical Artist's impression · drag to rotate
What it is a structure using a star's energy to do work or move it [1]
First idea 1948 Fritz Zwicky, fusion jets on the Sun [5]
Shkadov thruster 1987 Leonid Shkadov, a giant mirror [2]
Thrust on the Sun 1.28 × 10¹⁸ N reflecting half its light [2]
After a million years 20 m/s moved 0.03 light-years [2]
After a billion years 20 km/s moved 34 000 light-years [2]
Faster design Caplan thruster, 2019 about 10 parsecs in a million years [3]

About the image. Drawn as a Sun-like star with an enormous curved mirror on one side, reflecting light that pushes the star the other way. Proportions are imagined; a real Shkadov mirror would be far thinner and further from the star.

A civilisation that could build a Dyson swarm might want something more ambitious still: to move its star. Stars drift through the galaxy, and over millions of years they can pass dangerously close to each other or towards supernovae. A stellar engine is a structure that uses a star’s own energy to do work, and in its most dramatic form, to steer the star itself, taking its planets along with it.

Zwicky’s jets

The first proposal came from the Swiss astronomer Fritz Zwicky. In a lecture in 1948 he imagined firing fusion jets from the surface of the Sun to accelerate it, with the whole Solar System, towards Alpha Centauri at about 1 000 kilometres per second.

A mirror the size of an orbit

In 1987 the Soviet scientist Leonid Shkadov proposed a gentler method. Place an enormous curved mirror on one side of the star, at the distance where the star’s gravity pulling it in and its light pushing it out exactly balance, so the mirror hovers in place. The mirror reflects light back towards the star on one side. Because the star now shines more strongly in one direction than the other, it is pushed very slowly the opposite way, and the mirror, held by gravity, comes along.

The push is tiny but endless. Reflecting half of the Sun’s output would give a thrust of about 1.28 × 10¹⁸ newtons. After a million years, the Sun would be moving at only 20 metres per second and would have travelled 0.03 light-years. After a billion years it would reach 20 kilometres per second and have moved about 34 000 light-years.

In 2000 Viorel Badescu and Richard Cathcart sorted stellar engines into classes. The Shkadov thruster is Class A. A Class B engine is a Dyson-like shell that uses the star’s energy to drive machinery, and Class C combines the two.

Faster

In 2019 the physicist Matthew Caplan designed a more powerful engine. It would collect material from the star itself and fire it back out as a fast fusion jet, while a second jet holds the engine in place. By his calculation, such an engine could move a star about 10 parsecs, around 33 light-years, in as little as a million years.

Could we see one?

In 2013 Duncan Forgan suggested that if an alien civilisation had built a Shkadov thruster, the mirror might betray itself by distorting the light curve of a planet passing in front of the star. The chance of catching one is small, but the method would work with telescopes we already have.

Gallery

A yellow star with a curved mirror at its side, sending a broad beam of golden light out into space, an impression of a stellar engine pushing its star. AI-generated painting.
A huge dish-shaped mirror catching light and sending a golden beam off into space, an impression of the mirror of a stellar engine. AI-generated painting.
Stellar engine, 3D artist's impression, rendered from the interactive model.
Stellar engine, 3D artist's impression, from another angle, rendered from the interactive model.
Stellar engine, 3D artist's impression, close-up, rendered from the interactive model.

Timeline

  1. 1948 Fritz Zwicky proposes moving the Sun with fusion jets.
  2. 1987 Leonid Shkadov proposes a giant mirror.
  3. 2000 Badescu and Cathcart classify stellar engines.
  4. 2013 Duncan Forgan suggests how to detect one.
  5. 2019 Matthew Caplan designs a faster jet-driven engine.

Questions people ask

Can you move a star?

In theory. A Shkadov mirror reflecting half the Sun's light would move it about 34 000 light-years in a billion years.

What is a Shkadov thruster?

A huge mirror that reflects part of a star's light back on it, so the star is pushed slowly in the opposite direction.

Sources

  1. Wikipedia: Stellar engine (Badescu & Cathcart 2000)
  2. Wikipedia: Shkadov thruster
  3. Caplan (2019), Stellar engines: design considerations for maximizing acceleration, Acta Astronautica 165: 96
  4. Forgan (2013), On the possibility of detecting class A stellar engines using exoplanet transit curves, JBIS
  5. Centauri Dreams (2014): Fritz Zwicky on moving stars
